Dongfeng Dolica D8 6.5 meter Wrecker Truck

1 / 8

Dongfeng Dolica D8 6.5 meter Wrecker Truck

I. Basic Vehicle Parameters
Vehicle Model	ABC5122TQZ EQ6
II. Chassis Core Parameters
Cab	New Duolika D8 Single-row Wide-body Cab
Engine Model	Yuchai 165HP Engine
Transmission Model	Fast 8-speed Gearbox
Wheelbase	4400mm
Frame Specification	235 Reinforced Frame
Tire Specification	825R20 Steel Wire Tires (with Spare Tire)
Rear Axle Specification	7-ton Reinforced Rear Axle
Chassis Standard Configuration	Power Windows, Remote Key, Multi-function Steering Wheel, Air Horn, Original Factory Heating and Cooling Air Conditioner, Cruise Control Function
III. Upper Mounted Core Parameters
Upper Mounted Type	One-tow-two Type Upper Mounted
Upper Mounted Process	Sunken Upper Mounted Process (Lower Flatbed Center of Gravity)
Flatbed Ground Clearance	1.2m
Total Flatbed Length	6.5m
Flatbed Width	2.5m
Main Plate Length	5.4m
Tail Flip Length	1.1m
Flatbed Material	5MM Wear-resistant Patterned Steel Plate
Frame Specification	14MM Solid Steel Plate Frame with Cut Holes
Hinge Specification	Tail Through-shaft Detachable Flip Hinge
Chute Specification	10MM Manganese Steel Chute (8MM Steel Plate Reinforcement Outside the Bell Mouth)
Under-plate Structure	Encrypted Grid-shaped Frame, Encrypted Triangular Inclined Supports
Winch Specification	6-ton Winch
Rear Tow Arm Specification	6-ton Rear Tow Arm
Multiplex Valve Brand	Domestic Brand Multiplex Valve
Flatbed Telescopic Hydraulic Cylinder Specification	110
Lifting Hydraulic Cylinder Specification	110
IV. On-board Accessories Configuration
Accessory 1	One Set of Gantry Side Lights
Accessory 2	Two Rear LED Working Lights
Accessory 3	Four High-quality Binding Belts
Accessory 4	One Pair of Triangular Tire Blocking Plates
Accessory 5	One On-board Crowbar
Accessory 6	One Tool Box
Accessory 7	One Pair of Square Tire Holding Cylinders
Accessory 8	One Pair of Seven-shaped Forks
