Dongfeng 5-Cubic-Meter Foam Fire Truck

1 / 6

1. Basic vehicle parameters
Chassis Brand	Dongfeng
Total vehicle weight	11200kg
curb weight	7800kg
Rated water capacity	5100kg
Overall vehicle dimensions	7200×2250×3100mm
Top speed	85 km/h
2. Basic parameters of the chassis
Driver type	4x2, left-hand drive
Engine Model	YC4A180-60
horsepower	180HP / 132kWkW
gearbox	6-speed manual
Front axle/Rear axle	3.6 tons / 7.2 tons
wheelbase	3800mm
Tire specifications	8.25R20 12PR
Emission standards	Euro 6
3. Basic parameters of the upper part
Water tank capacity	5100L(Water tank: 3.6m³ carbon steel, corrosion resistant; foam tank: 1.5m³ 304 stainless steel)
Water tank material	5mm carbon steel, internal anti-corrosion treatment, orange-vein paint finish.
Fire pump rated flow	42L/s
Fire pump rated pressure	1.0MPa
Fire monitor rated flow	30L/s
Fire monitor rated pressure	0.8MPa
Fire monitor range	Water ≥ 65m, Foam ≥ 55m
Fire monitor rotates horizontally	360°, Pitch: -75° to +75°
Standard equipment	Fire hoses, fire axes, fire extinguishers, demolition tools, etc.
